THE NEW V Range
The V 500 LQ is a new development within the 500 kg capacity segment and the lightest version of the new V-range (from 500 up tp 1000 kg lifting capacity).
An aluminium platform with many options and its low maintenance effort features this new column lift.
| Model | V 500 LQ |
| Lifting capacity (kg) | 500 |
| Maximum width over columns (mm) | 2020 - 2220 |
| Maximum floor height (mm) | 1100 |
| Platform depths (mm) | 775 - 1225 |
| Platform type | Aluminium |
| Power closure version available | no |
| Flush side ramps available | yes |
| Safety gates available | yes |
| *Approx. lift weight (kg) | 150 |
